The Deltrol Controls 20547-82 is a general purpose relay with the following specifications:
Contact Type: 3PDT (Triple Pole Double Throw)
Current Rating: 13 Amps
Voltage Rating: 300 VAC / 28 VDC
Coil Voltage: 28 VDC
Mounting Type: Socket Mount
Series: 160 Series
Special Features: Flange Cover, QC Tab Terminal
This relay is designed for industrial machine control, energy management systems, and control panels. It's part of the 160 Series, which includes relays with up to 13 Amp loads and a Class F coil insulation system for high-temperature environments.
