by Ascent -. Center for Technical Knowledge (Author)
The ENOVIA V5-6R2018: DMU Navigator and Space Analysis learning guide is an introduction to the DMU workbenches of the ENOVIA suite of products. Digital Mock-Up (DMU) is primarily used as a viewing and analysis tool for 3D CAD data. You will be introduced to the DMU interface by viewing, manipulating and analyzing 3D model geometry. Specific focus is made on the Space Analysis workbench, which provides access to clash, sectioning, and comparison tools. Based on the results of these analyses, you will learn to create annotations directly on the 3D geometry in order to communicate information back to the designers.
Topics Covered
DMU user interface
Model navigation and visualization
File management
Measurement tools
Clash analysis
Sectioning
Distance and band analysis
Compare products
Arc through three points
3D annotations
Annotation views
Image capture
Printing images
Prerequisites
Access to the V5-6R2018 version of the software, to ensure compatibility with this guide. Future software updates that are released by Dassault Systèmes may include changes that are not reflected in this guide. The practices and files included with this guide might not be compatible with prior versions (i.e., V5-6R2017).
Completion of the CATIA V5-6R2018: Introduction to Modeling or CATIA V5-6R2018: Introduction for Managers & Reviewers course is recommended.
